    Switch Appliances

    Interface Masters offers wide selection of Switch Appliances based on the latest leading 10/25/40/100 GE switching technologies and utilize an X86 CPU modules for control plane and optional ARM, MIPS and Power PC modules for the data plane.

    Our Switch Appliances offer none blocking bandwidth of up to 6.4TB in fixed or modular configuration for applications that requires maximum scalability. They are ideal platforms for the next generation firewalls, WAN optimization, Application Delivery Controllers (ADC), Security Appliances, Deep Packet Inspection (DPI), network offload assist with SSL/IPSec.

    Tahoe Switch Appliances come with the latest Linux OS ready for you to load your software application. Interface Masters provides professional services to assist in porting. For a complete list of factory options and private labeling, please contact Interface Masters Technologies, sales department.

    Interface Masters proudly designs and manufactures our products in the Silicon Valley, USA and provides tier 1 service for all of our products. We offer quick turn hardware customization to meet a wide variety of requirements in a fast-paced environment. Please contact us for a comprehensive discussion on your OEM or data center needs.

    Tahoe-2624

    10/25/40/100G

    Interface Masters Technologies offers modular and fixed product configurations for10/25/40/100/400 GE switching based on the Broadcom Trident III switch SOC. The systems are targeted to be used as a Top of Rack (ToR) or Leaf and End of Row (Spine) Switches. They are compliant with version 1.0 of the Open Compute Project (OCP) Open Network Switch Specification; Interface Masters contributed the initial OCP switch.

    Switches 100/400G

    Interface Masters Technologies offers a 100/400G OpenSwitch compatible white box system which includes a fully-featured control plane stack with Layer 2 and Layer 3 networking protocol support.

    2664

    10/25/40/100G Switches

    Compare our lineup

      Tahoe-2624 switch appliance
    Tahoe 2624
    T2728-ProductImage
    Tahoe 2728
    Tahoe-2732
    Tahoe 2732
    T2748-6C
    Tahoe 2748-6C
    Product Intel Tofino Switch Appliance with Intel Control Plane, and Two Powerful Intel Offload Dataplanes. Includes Interface Masters proprietary Intel based DataSlammer™ technology Broadcom Trident 3 Switch Appliance with Intel Control Plane, and Two Powerful Intel Offload Dataplanes. Includes Interface Masters proprietary Intel based DataSlammer™ technology Broadcom Trident 3 Switch Appliance with Intel Control Plane, and Two Powerful Intel Offload Dataplanes. Includes Interface Masters proprietary Intel based DataSlammer™ technology Broadcom Trident 3 high-speed Switch Fabric Managed Switch Appliance with our proprietary Intel based DataSlammer™ technology
    Switch Fabric Intel Tofino Broadcom Trident 3 Broadcom Trident 3 Broadcom Trident 3
    Switch Fabric Part Number - BCM56850 BCM56850 BCM56850
    Control Plane CPU Intel x86 Intel x86 Intel x86 Intel x86
    Date Plane CPU Intel x86 Intel x86 Close-mark Intel x86
    Form Factor 1U 1U 1U 1U
    TPM Option tick-mark tick-mark tick-mark tick-mark
    Precision Time Protocol tick-mark tick-mark tick-mark tick-mark
    Port Speed: 1G Close-mark Close-mark Close-mark tick-mark
    Port Speed: 10G tick-mark tick-mark Close-mark tick-mark
    Port Speed: 25G tick-mark tick-mark Close-mark tick-mark
    Port Speed: 40G tick-mark tick-mark tick-mark tick-mark
    Port Speed: 100G tick-mark tick-mark tick-mark tick-mark
    No. of Ports: 1/10G Close-mark 2 2 Close-mark
    No. of Ports: 25/10G 24 8 Close-mark

    48

    No. of Ports: 100/40G 16 28 32

    6

    Availability Now Now Now Now
      Learn More Learn More Learn More Learn More

    Switches 100/400G

    Compare our lineup

      2664
    Tahoe 2664-ZR1
    Product Intel® Tofino™ 2 P4-programmable Switch Fabric Managed Switch
    Switch Fabric Intel® Tofino™ 2
    Switch Fabric Part Number BFN-T20-128Q-B1
    Control Plane CPU Intel XEON®-D, 2.2GHz
    Date Plane CPU AMD EPYC 2 Milan
    Form Factor 3U
    TPM Option tick-mark
    Precision Time Protocol tick-mark
    Port Speed: 100G tick-mark
    Port Speed: 400G tick-mark
    No. of Ports: 100/40G 48
    No. of Ports: 400G 16
    Availability In Development
      Learn More
