Tahoe 2668-ZR1

Marvell® Falcon™ Artificial Intelligence Accelerated Computing Switch Platform With AMD EPYC™ 2 Data Plane

NETWORK SWITCH Appliances

Tahoe-2664-ZR1

Interface Masters Technologies’ new Tahoe 2668-ZR1 managed network switch takes center stage with enterprise and government applications demanding dense 100/400G switching combined with a full 128-cores of AMD EPYC 2 Milan offload. Tahoe 2668-ZR1 is purpose-designed for machine learning, artificial intelligence and packet broker applications.

The 3U networking device features Marvell Falcon switch fabric (12.8Tb), and two AMD x86 EPYC 2 Milan offload processors (16 to 64-cores, up to 3.675GHz clock speed). The appliance includes Interface Masters’ proprietary DataSlammer® offload processing technology.

Three port configurations are available in standard form:

  • 64 ports of 100G (QSFP28)
  • 48 ports of 100G plus 16 ports of 100/400G
  • Tahoe 2668-ZR1 includes Linux and out-of-the-box EPYC system management software is available. Software configurations include white box with ONIE SDK (on Marvell Falcon) and a complete hardware specific SDK tool set for custom development. Support for Marvell Telemetry, Intelligence, Performance and Security (TIPS) and fully shared packet buffer with Advanced QoS.  Interface Masters is currently developing SONiC, Stratum and DENT support for Marvell Falcon.

Features

Tahoe-2664-ZR1

Marvell Falcon Switch Fabric

Intel Control Plane
  • Intel XEON®-D, 2.2GHz control plane
  • DataSlammer Technology
Two Powerhouses CPUs
  • 2 (two) AMD EPYC 2 Milan x86 processors (Offload)
  • 16 to 64-Cores (3.0GHz base clock, 3.675GHz)
  • Maximum 2048G memory (16x128G DIMMs, DDR4)
  • Up to 4TB storage
Dual Redundant Hot-Swappable Power Supplies
  • High-efficiency power supplies (AC/DC or DC/DC)
Management Interfaces
  • Dedicated Console and Management ports
Security
  • Standard Trusted Platform Module (TPM)
  • US designed and US manufactured
Other
  • Standard IEEE-1588 PTP support
  • ANSYS® thermal modeling optimization ensures optimal airflow and minimum internal turbulence
Software
  • Support Marvell Telemetry, Intelligence, Performance and Security (TIPS) and fully shared packet buffer with Advanced QoS.
  • Interface Masters is currently developing SONiC, Stratum and DENT support for Marvell Falcon.

Specifications

Environmental
Operating Humidity 5% - 95%, non-condensing
Operating Temperature -5°C to 45°C (23°F - 113°F)
Dimensions
  Inches Millimeter
Length 24.00 609.60
Height 5.25 133.5
 Width 17.15 435.61

Applications



Tahoe-2664-ZR1

Ordering Information

Part Number Description
T2668-ZR1-AC Tahoe 2668 switching appliance supporting forty-eight (48) ports of 100G, 16 ports of 100/400G, dual AMD 64-Core CPUs (3.675GHz maximum clock), 16x64GB RAM (3200mt/s), 2x1TB NVME SSD storage, redundant AC power supplies and field replaceable fans.
 T2668-ZR1-DC
Tahoe 2668 switching appliance supporting forty-eight (48) ports of 100G, 16 ports of 100/400G, dual AMD 64-Core CPUs (3.675GHz maximum clock), 16x64GB RAM (3200mt/s), 2x1TB NVME SSD storage, redundant AC power supplies and field replaceable fans.
 T2668-ZR1-AC2

Tahoe 2668 switching appliance supporting forty-eight (48) ports of 100G, 16 ports of 100/400G, dual AMD 64-Core CPUs (3.675GHz maximum clock), 16x64GB RAM (3200mt/s), 2x1TB NVME SSD storage, redundant AC power supplies and field replaceable fans.
 T2668-ZR1-DC2

Tahoe 2668 switching appliance supporting forty-eight (48) ports of 100G, 16 ports of 100/400G , dual AMD 64- Core CPUs (3.675GHz maximum clock), 16x64GB RAM (3200mt/s), 2x1TB NVME SSD storage, redundant DC power supplies and field replaceable fans.

Download Tahoe 2668-ZR1 Product Brief
